Copper Reducer

Copper Reducer Specification

benefit

Specification

ASTM B62 / ASME SB62

Standards

ASME/ANSI B16.9, ASME B16.28, MSS-SP-43

Size

3/4 inch, 1 inch, 1/2 inch, 2 inch, 3 inch, Custom

Thickness

5-20 Mm

Diameter

2-4 Inch

Working Temperature

-20 TO 100 Deg C, 100-200 Deg C

Types Of Copper Reducer

Copper Concentric Reducer

Copper Concentric Reducer

Copper Eccentric Reducer

Copper Eccentric Reducer

Copper Push Fit Reducer

Copper Push Fit Reducer

Copper Solder Reducer

Copper Solder Reducer

Copper Reducer Dimensions, Eccentric Copper Reducer, 28mm To 1 Inch Copper Reducer, 1 1/4 To 1 Copper Reducer, Copper Reducer Sizes, Copper Y Reducer, High Quality Copper Reducer, Copper Bell Reducer, Copper Reducer Exporter in India

Copper Reducer Chemical Composition

Element C10100 C10200 C11000 C12200
Copper (Cu) 99.99% 99.95% 99.90% 99.90%
Oxygen (O) 0.0005% 0.0010% - -
Phosphorus (P) - - - 0.015% - 0.040%
Iron (Fe) 0.0010% 0.0020% 0.050% - 0.150% 0.050%
Lead (Pb) 0.0005% 0.0010% 0.0050% 0.0050%
Zinc (Zn) 0.0005% 0.0010% 0.050% 0.050%
Others 0.0005% 0.0010% 0.0050% 0.0050%

Mechanical Property Of Copper Reducer

Property C10100 C10200 C11000 C12200
Tensile Strength (ksi) 45 42 32 30
Yield Strength (ksi) 20 18 12 12
Elongation (%) 5 10 40 45
Hardness (HV) 80 75 60 55

Copper Reducer Sizes

Item D1xD2 A L1 L2
8×6 8×6 17.0 6.8 5.3
10×6 10×6 20.0 7.8 5.3
10×8 10×8 18.0 7.8 6.8
12×8 12×8 23.0 8.6 6.8
12×10 12×10 21.0 8.6 7.8
14×10 14×10 27.0 10.6 7.8
14×12 14×12 25.0 10.6 8.6
15×10 15×10 26.0 10.6 7.8
15×12 15×12 25.5 10.6 8.6
15×14 15×14 25.6 10.6 10.6
16×10 16×10 27.3 10.6 7.8
16×12 16×12 27.0 10.6 8.6
16×14 16×14 27.0 10.6 10.6
16×15 16×15 25.0 10.6 10.6
18×10 18×10 30.0 12.6 7.8
18×12 18×12 29.4 12.6 8.6
18×14 18×14 30.0 12.6 10.6
18×15 18×15 29.0 12.6 10.6
18×16 18×16 28.3 12.6 10.6
22×12 22×12 36.0 15.4 8.6
22×14 22×14 37.0 15.4 10.6
22×15 22×15 34.7 15.4 10.6
22×16 22×16 34.5 15.4 10.6
22×18 22×18 35.0 15.4 12.6
22×20 22×20 33.0 15.4 15.4
28×12 28×12 43.0 18.4 8.6
28×14 28×14 42.0 18.4 10.6
28×15 28×15 44.0 18.4 10.6
28×16 28×16 44.0 18.4 10.6
28×18 28×18 42.0 18.4 12.6
28×22 28×22 42.2 18.4 15.4
35×18 35×18 58.0 23.0 12.6
35×22 35×22 52.7 23.0 15.4
35×28 35×28 49.5 23.0 18.4
42×22 42×22 65.5 27.0 15.4
42×28 42×28 62.0 27.0 18.4
42×35 42×35 59.5 27.0 23.0
54×22 54×22 80.0 32.0 15.4
54×28 54×28 75.0 23.0 18.4
54×35 54×35 77.0 27.0 23.0
54×42 54×42 76.3 32.0 27.0
64×35 64×35 44.0 33.3 23.0
64×42 64×42 41.0 33.3 27.0
64×54 64×54 32.5 33.3 32.0
67×54 67×54 30.0 33.3 32.0
70×64 70×64 28.0 33.3 33.3
76.1×54 76.1×54 39.5 33.5 32.0
76.1×64 76.1×64 34.0 33.5 32.0
80×64 80×64 38.0 33.5 33.3
88.9×76.1 88.9×76.1 38.0 47.5 33.5
108×88.9 108×88.9 44.0 47.5 47.5
159×108 159×108 152.5 70.0 47.5

Copper Reducer Physical Property

Property Value
Density 8.96 g/cm3
Thermal Conductivity 385 W/mK
Electrical Conductivity 58 MS/m
Coefficient of Thermal Expansion 16.5 × 10-6/K
Melting Point 1084°C
